AMT-130 Semi-Automatic Tubing Cutter
Our fastest tubing cutter! The AMT-130 Semi-Automatic Tubing Cutter provides a fast and accurate means of cutting tubing. This device features one-touch automated cutting action, a cut counter, an easily adjustable stop block (with cut button), and a stainless steel scale with both Metric and English units. Cut speeds achievable up to a cut per second!
Three lenghts of the AMT-130 are available: 24", 36", and 48". Electrical outlet and compressed air are required for operation. Features a grained and polished 304 Stainless Steel frame. This device has safety features to mitigate accidents with exposed blades and is designed to be compatible with Class 10,000/ISO 7 clean room applications.
The safety features of this product:
- Cut Button - The blade will not actuate without the Cut Button being pressed.
- Cover Detection Switch - If the electronics cover is removed, the power to the device will disconnect, rendering the device inoperable until the cover is replaced.
- Bushing Detection Switch - If the outlet bushing is removed, the power to the device will disconnect, rendering it inoperable until the bushing is replaced.
Technical Specifications
- Cuts flexible tubing, including heat shrink and non-metallic braided materials, up to a Shore A 85 durometer
- Cuts tubing diameter 1/32" to 1/2"
- Bushing sets for standard tubing sizes (1/8", 3/16", 1/4", 5/16", and 3/8") are available
- Cuts lengths from 3/4" to 24", 36", or 48"
- In most cases .03” to .88” cut lengths are achievable using a stop tool. Contact AMT Devices engineering group for more details.
- General cut tolerance +/- 1/32", in some cases +/-.005"
- Unit weight: 24" [8.2lbs/3,7kg], 36" [9.5lbs/4,3kg], 48" [10.0lbs/4,5kg]
- Overall Dimensions: 9.0" W x 6.5" H x 29", 41", & 53" L
- Requires 80-100 psi air
- Requires 120VAC (North America) or 230VAC (Europe)
AMT-130 Models
- 130-24 - 24" Maximum cut length
- 130-36 - 36" Maximum cut length
- 130-48 - 48" Maximum cut length
